UL94 ID10mm Non-shrink PTFE Tube 5M with High Electrical Resistance and Corrosion Resistance

Name: UL94 ID10mm Non-shrink PTFE Tube 5M with High Electrical Resistance and Corrosion Resistance
Brand: Changzhou Longchuang Insulating Material Co., Ltd.
SKU: 10mm
Price: 0.05 USD
Availability: InStock

Markenname:	None
Modellnummer:	10mm
MOQ:	1
Preis:	negotiable
Zahlungsbedingungen:	T/T
Versorgungsfähigkeit:	10000 Meter Tag

Einzelheiten

Produktbeschreibung

Einzelheiten

Herkunftsort:

Jangsu China

Zertifizierung:

ISO9001

Material:

Teflon

Größe:

ID10mm L5M

Farbe:

Weiß, Rot, Gelb, Blau, Grün, Schwarz, Klar usw.

elektrischer Widerstand:

Hoch

Volumenwiderstand:

über 1x10^18Ω·cm

Dehnungsfestigkeit:

mehr als 200%

Dielektrischer Widerstand:

fast 2.1

Zugfestigkeit:

über 13,7 N/mm

Flexibilität:

Gut

Wasserdicht:

Wasser-, Öl-, Lösungsmittel-, Säure- und Alkalibeständigkeit

Altern:

Anti-Aging

Verpackung Informationen:

Karton

Versorgungsmaterial-Fähigkeit:

10000 Meter Tag

Hervorheben:

Non-shrink PTFE tube 5M

PTFE tube high electrical resistance

Corrosion resistant PTFE tubing

Produktbeschreibung

Description :

High PTFE tube with non-shrinking is extruded from high quality PTFE resin with no heat shrinkable property ,stable dimension and high mechanical strength .It features excellent high and low temperature resistance ,corrosion resistance and high insulation performance .Colored types are available for line identification ,widely used in harsh conditions such as electrical ,chemical ,medical and aerospace fields.

Key Feature :

Stable material ,non-shrinking and non-deforming ,high dimensional accuracy.
Operating temperature :-190 to 260 °C
Excellent chemical resistance to strong acids ,alkalis ,organic solvent and oils
Excellent electrical insulation ,low dielectric loss ,high insulation strengh
Low friction ,non-stick ,anti-aging ,weather resistant and UV resistant
Non-toxic and eco-friendly ,compliant with RoHS ,REACH ,partly FDA compliant
Various colors available for easy line identification

Typical applications :

Insulation sleeces for high frequency signal wires ,coaxial cables and sensors
Harness identification ,wire protection and terminal insulation
Protection tubes for transformers ,capacitors ,connectors and PCB circuits
Transfer tubes for highly corrosive chemicals and gases
Laboratory tubing ,analytical instruments and chromatograph catheters
Oil pumps ,hydraulic systems and oil and corrosion resistant sleeves
Medical catheters ,endoscope protection tubes and presion instrument sheaths
Hygienic transfer tubes for food ,beverage and filling equipment
Heat insulation tubes for engine wiring harnesses ,anti-corrosion tubes for fuel systems
Aerospace instrument wiring ,hydraulic pipelines and high temperature wire protection
